Electronic Throttle Body For Opel Antara 2012 – 65mm – OE12632093BA – LOREADA

OE Numbers: 12632093BA / 12670836 / 12632093 / 12669148

Bore Diameter: 65mm | Direct OEM Replacement | 12+24 Month Warranty | 100% Factory Tested

Vehicle Fitment – Compatible with:

⚠️ Important: This throttle body is designed for 2.4L naturally aspirated petrol engines (GM LE5 / LE9 / Z24SED). Antara and Captiva share the same Theta platform and engine family. Please verify your original OE number before ordering. Diesel variants (2.0L, 2.2L CDTI) use a different throttle/intake valve assembly and are NOT compatible.-

OE Cross Reference – Match with your original part:

ℹ️ *This throttle body is compatible with Febi Bilstein part number 103556, which undergoes rigorous OE-matching quality testing including dimensional accuracy, material quality, and tensile strength validation.*-

Technical Specifications

ℹ️ *All OE-grade throttle bodies are 100% factory-tested for thermal cycling, airtightness, and full-stroke angle calibration. The 6-pin connector is the standard configuration for GM Theta-platform 2.4L applications.*

Product Highlights

✅ OE Fitment – Developed to strict OEM standards. Direct replacement – no wiring modification or splicing required.
✅ Theta Platform Optimized – Specifically engineered for Opel Antara and Chevrolet Captiva 2.4L LE5/LE9 engines, sharing the GM Theta platform architecture.
✅ Plug & Play Installation – Exact match in dimensions, connector pinouts (6-pin), and electrical parameters. Uses factory mounting bolt pattern.
✅ High Performance – Motor response time ≤ 50 ms for precise intake control, smooth acceleration, and improved throttle sensitivity.
✅ Reliability – Built-in dual redundant position sensors prevent idle fluctuations, hunting, and false error codes.
✅ Rigorous Testing – 100% factory-tested for thermal cycling, airtightness, and full-stroke angle calibration by OE-grade manufacturers.
✅ Standard Compliance – Meets ISO 16750 environmental standards for automotive electrical/electronic equipment.
✅ Proven Aftermarket Support – Cross-referenced with Febi Bilstein 103556, a trusted OE-quality aftermarket brand.

Common Symptoms of a Failing Throttle Body (Opel Antara 2.4L)

• Unstable idle, “hunting,” or engine stalling at stops

• Check Engine Light (CEL) – common DTCs: P0120, P0122, P2112, P2119, P2101, P2135-

• Hesitation or flat spot during acceleration

• Poor throttle response / delayed acceleration

• Reduced power / limp mode

• Rough idle that improves when throttle is applied

• Engine dies when coming to a stop

• Poor fuel economy

These symptoms are frequently reported for high-mileage Antara and Captiva vehicles when the throttle body components wear out or carbon buildup occurs.-

Installation & Adaptation Tips

IMPORTANT: After replacing the Electronic Throttle Body (ETB) on Opel Antara / Chevrolet Captiva, a throttle self-learning / idle relearn procedure is REQUIRED. Some diagnostic tools offer a “Throttle Body Reset” special function.-

Step-by-Step Procedure:

For Opel Antara 2.4L / Chevy Captiva: The above procedure typically works. If issues persist, use a professional diagnostic scanner (e.g., GM MDI / Tech2 / OPCOM) to perform a “Throttle Body Adaptation” or “Idle Relearn”. After replacement, it may take a few drive cycles for the ECU to fully adapt to the new throttle body.-

Packing List

• Electronic Throttle Body Unit (65mm bore) × 1

• Installation Gasket / Seal (if applicable) × 1

• Warranty Card / Quality Certificate × 1

• (Optional: Screws / Connector protector – may vary by batch)

How to Ensure You Get the Correct Part

1. Confirm your vehicle is an Opel Antara (2012) or Chevrolet Captiva (2011–2018) with the 2.4L petrol engine (LE5 / LE9 / Z24SED). Diesel models are NOT compatible.-

2. Check your original part number on the existing throttle body.

3. Match your OE number with 12632093BA, 12670836, 12632093, or 12669148.

4. Verify the connector has 6 pins (OEM specification for this application).

5. Contact us with your VIN or a photo of your original part if unsure.

After-Sales & Disclaimer

• Pre-installation check: Inspect the throttle body for any defects. Verify the OE number and connector type (6-pin) before installation.

• Compatibility: This throttle body is for 2.4L naturally aspirated petrol engines ONLY. It will NOT fit Antara / Captiva diesel variants (2.0L, 2.2L CDTI) or older 3.2L V6 models without verification. Antara (2006–2015) and Captiva share the same Theta platform – fitment applies to both.-

• Gasket requirement: A new mounting gasket is strongly recommended for proper sealing and to prevent vacuum leaks.

• Professional installation recommended: While installation is straightforward, proper adaptation is critical. If you are not comfortable performing the relearn procedure, professional installation is recommended.

• Warranty: This product carries a 12-month warranty against manufacturing defects. The motor and sensors are covered for 24 months.

🛠️ Quick Reference Card (for Print/Inclusion)
